| Model Number : | GS250A-3.5 |
| Certification : | CE, RoHS, SGS, ISO9001, ISO14001 |
| Payment Terms : | Paypal ,Western Union, MoneyGram, T/T |
| Supply Ability : | 10000000pcs/month |
| Delivery Time : | 3-5 days for sample order or according to your order quantity |
Specification:
| Electrical | ||
| Standard | UL | IEC |
| Rated voltage | 300V | 250V |
| Rated current | 2A | 2A |
| Wire range | 24-20AWG | 0.2-0.5mm2 |
| Withstanding voltage | AC2000V/1Min | |
| Mechanical | ||
| Ambient temperature | -40°C~+105°C | |
| Strip length | 8.5-9.5mm | |
| Size | ||
| Pitch | 2.5mm(.098") 2.54mm(.100") | |
| Poles | 1P-XXP | |
| Material | ||
| Housing | PA66,UL94V-0 | |
| Pin header | Phosphor bronze,Tin plated | |
Application:

|   |
